PLC programmable controller 1N-20MR DC Relay module with Base Industrial Control Board Programmable Logic Controller

PLC wiring diagram as above (XC is 0V)

As long as the touch screen supports fx1n and has 232 interface, you can communicate with this PLC

Product function description:

Write applications in ladder diagram language with support for Mitsubishi GX developer8.xx, GX-Work2.

Working voltage: DC 22V- 28V.

Relay load capacity: AC no more than 220V 5A, DC no more than 30V 5A

Support human-machine interface connection, text display (as long as the touch screen support fx1n can, we have done experiments: excellent control, display control, step, Vilun Tong, Kunlun Tong state, etc.).

Support ladder diagram programming, download, monitoring, batch soft original monitoring, memory clearance.

The programming port is the port to download the program and communicate with the man-machine interface.

This PLC adopts the industrial grade 32 - bit MCU with strong anti - interference.

Password protection, as long as the password is 12345678 internal procedures are protected, to prevent your program from being illegally stolen, protect the fruits of your labor. If the password is set to 12345678, there will be no program reading function on the board. You will only be able to download the program and the "Parameters" option will not be checked. Unable to unlock password lock!!

Download baud rate support: 9600 (default)

Support two wire proximity switch, when the proximity switch is near the screwdriver Y2 input voltage, X2 output voltage
